Features:

• Control (3):  Front mount only

• Air discharge orientation: End of cabinet only

• Duct collars: 8"

• Backdraft damper: No

• Filter: 1/2" MERV 8 washable

• Refrigerant: R410A

• Coil type: Aluminum

• Power cord length: 8 ft

• Hardwire option: No

• Discharge air temperature rise: 10°F – 30°F

• Drain connection (4): 3/4" MNPT Threaded

Specifications:

• Capacity (1): 70 ppd

• Energy Factor (1): 2.1 L/kW-h

• Airflow @ varying E.S.P. (external static pressure - dry coil): 0.0" w.c.-200 CFM, 0.2" w.c.-170 CFM, 0.4" w.c.-140 CFM

• Current draw (1): 5.8 Amps

• Noise: 53 dBA ducted - 58 dBA unducted

• Dimensions (cabinet only) (2): Width 12.5" - Height 12.5" - Length 25.0"

• Weight: 56 lbs

• Inlet air operating conditions during: -Dehumidification: 50°F – 104°F, 40°F dew point min. -Ventilation: 40°F – 140°F, 0% – 99%RH (non-condensing)
